Interface Definition
| Pin Number | Mark | Description |
|---|---|---|
| 1,17 | 3.3V | Power Positive (3.3V power input) |
| Twenty four | 5V | Power supply positive (5V power input) |
| 3,5,7,8,10,22 | NC | NC |
| 6,9,14,20,25 | GND | Power Ground |
| 11 | TP_IRQ | Interrupt touch panel, the touch panel is pressed is detected compared to low |
| 12 | KEY1 | Button |
| 13 | RST | Reset |
| 15 | LCD_RS | LCD command control, command / data register select |
| 16 | KEY2 | Button |
| 18 | KEY3 | Button |
| 19 | LCD_SI / TP_SI | LCD display / touch panel SPI data input |
| Twenty one | TP_SO | SPI data output of the touch panel |
| Twenty three | LCD_SCK / TP_SCK | LCD display / touch panel SPI clock signal |
| Twenty four | LCD_CS | LCD chip select signals, low-level selection LCD |
| 26 | TP_CS | The touch panel chip select signals, low-level selection touch panel |
