Bộ chuyển đổi HDMI to USB 3.0 dành cho Raspberry Pi, Jetson Nano, Gaming, Streaming, Cameras

Bộ chuyển đổi HDMI to USB 3.0 dành cho Raspberry Pi, Jetson Nano, Gaming, Streaming, Cameras

  • MLAB00757
  • Waveshare
398,000

Sản phẩm nhập khẩu chính hãng từ Waveshare

Hỗ trợ kỹ thuật trong quá trình sử dụng

Xuất hóa đơn VAT cho cá nhân, đơn vị có nhu cầu

Sản phẩm được bảo hành 06 tháng



USB Port High Definition HDMI Video Capture Card, For Gaming / Streaming / Cameras, HDMI To USB

USB HD Video Capture Card

HDMI to USB, Driver-free

 HDMI to USB3.0 Adapter

USB3.0 Version

USB 3.0 VERSION DESCRIPTION

   Marketing Name   Logo   USB3.2 Specification   Old Specifications   Transfer Speed
   USB 5Gbps   USB 3.2 Gen 1x1   USB 3.1 Gen 1   USB 3.0   5Gbit/s

MUA COMBO HDMI to USB3.0 AdapterHigh-Speed Cable HDMI to HDMI (LINK

TRỌN BỘ SẢN PHẨM: 448.000VNĐ / COMBO

ĐẶC ĐIỂM, TÍNH NĂNG



HDMI Input

- Compatible with HDMI 1.4B

- Support DVI1.0

- Support HDCP1.4

- Support RGB444/YCBCR422/YCBCR444/YCBCR420

- Support color depth 24/30/36-bit mode

- Support CEA-861/CEA-861-F video format

- Max. support resolution: 4K(3840*2160@30Hz)







USB Output

- Support USB 3.0 Device

- Compatible with USB 2.0 device mode

- Compatible with UVC1.0 protocol

- Support YUV422 and MJPEG mode

- Maximum supported resolution: 1080P (1920*1080@60Hz)

- Support YUV422 and MJPEG mode

- Support user-define resolution

- USB video is compliant with the UVC1.0 protocol

- USB audio is compliant with the UVC1.0 protocol

THÔNG SỐ KỸ THUẬT

INPUTHDMI
Input resolution up to 4K (3840*2160@30Hz)
HDMI 1.4B compliant
OUTPUTUSB3.0
Output resolution up to 1080P (1920*1080@60Hz)
Supports YUV422 and MJPEG modes
UVC1.0 and UAC1.0 protocol compliant
TRANSMISSION LATENCY*As low as 50ms
AUDIODefault 48KHz stereo output
SYSTEM SUPPORTWindows, Linux, macOS, Android
SOFTWARE SUPPORTOBS, Potplayer, QuickTime, XSplit, etc.

* test data are from Waveshare laboratory, and the actual performance may be different according to the device you are using.

HỖ TRỢ CHO NHIỀU THIẾT BỊ

Easy Use With Different Hosts Like:

Smartphone, Game Console, Set-Top Box, Camera...

* The video output ports may be different, an additional corresponding adapter cable is required for different hosts.

SỬ DỤNG VỚI RASPBERRY PI

Sản phẩm không bao gồm Cable HDMI

HÌNH ẢNH SẢN PHẨM



KÍCH THƯỚC BÊN NGOÀI

TÀI LIỆU THAM KHẢO

Wiki : www.waveshare.com/wiki/HDMI_to_USB3.0_Adapter
