Power Over Ethernet HAT (F) For Raspberry Pi 5, High Power, Onboard Cooling Fan, With Metal Heatsink, Supports 802.3af/at network standard
POE HAT for Raspberry Pi 5
Power Over Ethernet HAT For Raspberry Pi 5, Supports 802.3af/at Network Standard
12V and 5V power outputs to support more peripherals
Từ 2022 MLAB có thêm website mlab.com.vn với nền tảng web mới hơn, dễ sử dụng hơn cho quý khách hàng tra cứu, đặt hàng online tại MLAB. Quý khách hàng có thể mua PoE HAT (F) tại MLAB tại link: (link đặt hàng)
Features at a glance
The PoE HAT (F) is a 802.3af/at-compliant Power Over Ethernet accessory for the Raspberry Pi 5. By using this small HAT and some proper 802.3af/at-compliant power sourcing equipments, it is possible to provide both network connection and power supply for your Raspberry Pi in only one Ethernet cable.
- Standard Raspberry Pi 40PIN GPIO header, supports Raspberry Pi 5
- PoE (Power Over Ethernet) capability,IEEE 802.3af/at-compliant
- Fully isolated switched-mode power supply (SMPS)
- Onboard high speed active cooling fan, with metal heatsink, better heat dissipation
Specifications
PoE power input | 37V ~ 57V DC in |
---|---|
Power output | GPIO header: 5V 4.5A (MAX) 2P header: 12V 2A (MAX) |
Dimensions | 56.5 × 70.0mm |
Network standard | IEEE 802.3af/at PoE |
Suitable for Raspberry Pi 5
Standard Raspberry Pi 40PIN GPIO stackable header, allows connecting other HATs
Power Over Ethernet
Providing both network connection and power supply for your Raspberry Pi in one cable
Onboard 5V & 12V header outputs
5V header provides up to 4.5A output (MAX 25W for 12V+5V total output power)
be able to power extra devices while providing stable power to Raspberry Pi
Active Cooling fan
Accelerate Cooling Effect, More Stable Performance
Onboard MP8759GD buck chip
Incorporates original voltage buck chip
providing up to 5A under sufficient heat dissipation condition
How to Install
Attach the thermal tapes first, then install metal heatsink and fix the PoE HAT
For reference only, please refer to the Package Content for detailed part list
Use with Case and SSD M.2 HAT
+ Industrial Grade Metal Case (D) dành cho Raspberry Pi 5 (LINK HERE)
+ PCIe to M.2 NVMe SSD (LINK HERE) hoặc PCIe to 2-CH M.2 HAT Dual NVMe SSD (LINK HERE)
