Raspberry Pi AI Kit (M.2 HAT+ with a Hailo AI acceleration module) for Raspberry Pi 5
Từ 2022 MLAB có thêm website mlab.com.vn với nền tảng web mới hơn, dễ sử dụng hơn cho quý khách hàng tra cứu, đặt hàng online tại MLAB. Quý khách hàng có thể mua Raspberry Pi AI Kit tại MLAB tại link: (link đặt hàng)
Feature
- 13 Tera-Operations Per Second: Contains a neural network inference accelerator capable of 13 tera-operations per second (TOPS)
- Fully Adapted Camera: Fully integrated into Raspberry Pi’s camera software stack
- Good Heat Dissipation Effect: Thermal pad pre-fitted between module and HAT+ spreads heat across components, improving performance
- Reserved Interface: Supplied with 16mm stacking header, spacers, and screws to enable fitting on Raspberry Pi 5 with Raspberry Pi Active Cooler in place
Description
The Raspberry Pi AI Kit bundles the Raspberry Pi M.2 HAT+ with a Hailo AI acceleration module for use with Raspberry Pi 5. It provides an accessible, cost-effective, and power-efficient way to integrate high-performance AI. Explore applications including process control, security, home automation, and robotics. Contains:
- a Hailo AI module containing a Neural Processing Unit (NPU)
- a Raspberry Pi M.2 HAT+, to connect the AI module to your Raspberry Pi 5
- a thermal pad pre-fitted between the module and the M.2 HAT+
- a mounting hardware kit
- a 16mm stacking GPIO header
The AI module is a 13 tera-operations per second (TOPS) neural network inference accelerator built around the Hailo-8L chip. The module uses the M.2 2242 form factor and comes pre-installed in the M.2 HAT+, to which it connects through an M key edge connector. The M.2 HAT+ communicates between the AI module’s M.2 interface and the Raspberry Pi 5’s PCIe 2.0 interface. When the host Raspberry Pi 5 runs an up-to-date Raspberry Pi OS image, it automatically detects the Hailo module and makes the NPU available for AI computing tasks. The built-in rpicam-apps camera applications in Raspberry Pi OS natively support the AI module, automatically using the NPU to run compatible post-processing tasks.
Specifications
Interface | 16mm stacking header |
Operating temperature | 0℃ to 50℃ |
Part List
Raspberry Pi M.2 HAT+ | x 1 |
Hailo AI Module | x 1 |
Hardware Overview
Hailo AI Module
