CM4 To Pi 4B Adapter for Raspberry Pi, Alternative Solution for Raspberry Pi 4B, CM4 optional

CM4 To Pi 4B Adapter for Raspberry Pi, Alternative Solution for Raspberry Pi 4B, CM4 optional (Bảo hành 6 tháng)

  • 23508
  • Waveshare
538,000

Sản phẩm được nhập khẩu chính hãng từ Waveshare

Hỗ trợ kỹ thuật trong quá trình sử dụng

Xuất hóa đơn VAT cho cá nhân, đơn vị có nhu cầu

Sản phẩm được bảo hành 6 tháng

Bảo hành 6 tháng
  • Bảo hành 6 tháng

Raspberry Pi CM4 To Pi 4B Adapter  Alternative Solution for Raspberry Pi 4B

THIẾT KẾ DÀNH CHO CM4 CỦA BẠN

- Need a Pi4B with eMMC function while the TF card is not very stable? This adapter is designed for you

- If you need 4-ch USB3.0 and dislike the slow USB2.0 interface, you can choose this adapter

- Suitable for application scenarios that require a wider temperature range

  • Need to find an alternative solution for your product which is designed based on the Raspberry Pi 4B



ĐẶC ĐIỂM, TÍNH NĂNG

- Onboard standard CM4 connector, support access to CM4 Lite / eMMc series boards with Quad Core Cortex A72 64-bit processor, more powerful performance

- Easily compatible with the interfaces of Raspberry Pi 4B board

- Onboard 4-ch USB 3.0 ports, compatible with USB 2.0 / 1.1 transmission

- Onboard RJ45 Gigabit Ethernet port, 10 / 100 / 1000 M adaptive

- Onboard PoE header, for connecting PoE HATs

Based On Raspberry Pi CM4

Use CM4 To Reproduce The Original Appearance Of The Pi 4B As Much As Possible
More Cost-Effective Choice


for reference only, CM4 is NOT included

DỄ DÀNG KẾT NỐI

Onboard Standard CM4 Connector
Support Access To Compute Module 4 Lite / EMMC Series Boards

for reference only, CM4 is NOT included



CÁC LỰA CHỌN

This Adapter Board Supports All Variants Of Compute Module 4
Currently Available CM4 Options (With Wireless) Are Listed Below

PART NUMBERRAMEMMC FLASHRECOMMENDED REASON
CMPI41010081GB8GBWith WiFi, suitable for applications with low RAM requirement
CMPI41010161GB16GB
CMPI41020082GB8GBAlternative solution for Pi4B-2GB version
With WiFi and eMMC
CMPI41020322GB32GB
CMPI41040084GB8GBAlternative solution for Pi4B-4GB version
With WiFi and eMMC
CMPI41040324GB32GB


Compatible With Pi 4B Series HATs

Easy Access To Pi 4B Series HATs Or Other Development Projects

for reference only, RS485 CAN HAT (B) is NOT included.

GIAO DIỆN KẾT NỐI



HÌNH DÁNG VÀ KÍCH THƯỚC

TÀI LIỆU THAM KHẢO

Wiki: https://www.waveshare.com/wiki/CM4-to-Pi4-Adapter
