Official Raspberry Pi Compute Module 5 IO Board

Mã sản phẩm: CM5-IO
Thương hiệu: RaspberryPi (UK)

698,000 ₫

Official Raspberry Pi Compute Module 5 IO Board dành cho CM5

Sản phẩm nhập khẩu chính hãng từ Raspberry Pi

Hỗ trợ kỹ thuật trong quá trình sử dụng

Xuất hóa đơn cho cá nhân, đơn vị có nhu cầu

Thêm vào giỏ hàng

Mô tả
Điểm nổi bật
Thông tin
Bình luận

Official Raspberry Pi Compute Module 5 IO Board, A Development Platform And Reference Base-board Designed For CM5, Suitable For All Variants Of Compute Module 5

Compute module 5 IO Board

The Compute Module 5 IO Board is a companion board for Raspberry Pi Compute Module 5 (supplied separately). It is designed for use both as a development system for Compute Module 5 and as an embedded board integrated into end products.

The IO board is designed to allow you to create systems quickly using off-the-shelf parts such as HATs and PCIe modules. The major user connectors are located along one side to make enclosures simple.

Specifications

CM5 socket	suitable for all variants of Compute Module 5
network	Gigabit Ethernet RJ45 port
network	Supports PoE function, onboard PoE header, an external PoE module (NOT included) is required
Connectors	Raspberry Pi 40PIN GPIO header
Connectors	M.2 M-Key PCIe socket, compatible with 2230, 2242, 2260 and 2280 form factors
USB	2 x USB3.2 Gen1 connectors 1 x Type-C port for updating Compute module 5
MIPI	2 x 4-lane MIPI DSI/CSI-2 connectors
Video	2 x HDMI ports with 4K support
RTC	Real-time clock with CR / ML2032 battery socket
Storage socket	MicroSD card socket for Compute Module 5 Lite (without eMMC) variants
Fan connector	5V, JST-SH PWM 4PIN connector
Power input	5V @5A via Type-C port, the same standard as the Raspberry Pi 5
Dimensions	160 × 90mm

Supports M.2 NVMe Solid State Drive

Faster reading/writing speed compared to the Micro SD slot of Raspberry Pi, greatly improving reading/writing efficiency of the system or files, support booting Raspberry Pi from NVMe Solid State Drive
