Grove Base Hat for Raspberry Pi - 24-Pin GPIO maintain, Grove interface for 3× I2C, 1× UART, 6× Digital, 4× Analog, SWD Debug interface, 1x PWM Port

Mã sản phẩm: 103030275

328,000 ₫

--- Quý khách hàng có nhu cầu có thể đặt hàng trước ---

Sản phẩm nhập khẩu chính hãng từ Seeed Technology

Hỗ trợ kỹ thuật trong quá trình sử dụng

Xuất hóa đơn cho cá nhân, đơn vị có nhu cầu

Sản phẩm được bảo hành 06 tháng

Thêm vào giỏ hàng

Mô tả
Điểm nổi bật
Thông tin
Bình luận

Từ 2022 MLAB có thêm website mlab.com.vn với nền tảng web mới hơn, dễ sử dụng hơn cho quý khách hàng tra cứu, đặt hàng online tại MLAB. Quý khách hàng có thể mua Grove Base Hat for Raspberry Pi - 24-Pin GPIO maintain tại MLAB tại link: (link đặt hàng)

Grove Shield for Raspberry Pi is an expansion board for Raspberry Pi, designed by Seeed Studio, for the orderliness of your connected sensors when you develop projects with Pi. It maintains 24-pin GPIO and provides 15 additional Grove ports based on the MM32 chip, along with other interfaces, giving you a great and quick development experience.

Feature

Grove & GPIO Pi Hat for Raspberry Pi Series: Break out all the pins and power of the Raspberry Pi to provide 15 multi-function Grove ports and compatible 24-pin GPIO based on a 12-bit ADC MM32 chip
Rich Peripherals for Grove: Provide 15 Grove ports including 3× I2C, 1× UART, 6× Digital, and 4× Analog, which also contains 1x PWM port, and the SWD Debug interface.
Plug and Play: Benefit from convenient Grove connectors that support more than 60 Grove modules

Description

This is the enhanced Grove Pi Hat for Raspberry Pi 2 / 3B / 3B+ / 4 / Zero, represented by Seeed Studio, where it breaks out all the pins and power of the board to produce 15 multi-function Grove ports and leads out the compatible Pi 24-Pin GPIO, SWD debug interface. With its convenient feature and the entire Grove system supported, it will be your good assistant when you try to start your projects with Raspberry Pi.

Powered by the MM32F031F6P6 chip, the 15 onboard Grove connectors are designed as 3*I2C, 1*UART communication ports,1* PWM port, and 4*Analog with 6*Digital transmitted ports, which support more than 60 related Grove modules. This Pi Hat also comes up with the Raspberry Pi compatible 24-pin GPIO and the SWD debug interface for further usage at the same time without pulling out.

What is Grove?

Grove is an electronic component ecosystem launched by Seeed Studio where it assembles actuators, displays, sensors, wireless modules, and other units, more than 300 in the total count, all sharing the same Grove data transmitted cable.

Application

Projects with Grove sensors
Electronics beginning
SWD debug
Rapid prototyping
Intelligent control

Specification

Parameter

Description

MCU

MM32F031F6P6

Operating Voltage

3.3V

Dimensions

55mm x65mm x20mm

Weight

G.W 24.5g

Battery

Exclude

Note

Please note that we have changed the chip from the original one STM32 to the new one MM32, where the I2C address has changed from 0x04 from 0x08.
